Flexible Ribbon High Brightness Led Strip (Non-Waterproof)

TECHNICAL PARAMETERS:

Led Light Source: 0.3W 5050 SMD LED
Standard:Regular Ribbon: 150 LEDs per roll (16.25 feet), ELT Approved: 600 LEDs per roll
Beam Angle: 120 degrees
Working Voltage: 12VDC (FL-RBL-HB-XX & UL-RBL-HB-XX), 24VDC (ETL-RBL-HB-XX)
Working Current: 600mA per meter (3.28 feet)
Power Consumption: 2.50 watts per foot (40watts per roll)
Led Light Output Per Roll: W: 3000lm, NW: 2900lm, WW: 2700lm
Package: 16.25 feet per roll (5 meters)
FL-RBL-HB-XX Colors: FL-RBL-HB-WW (Warm White), FL-RBL-HB-W (Cool White), FL-RBL-HB-BL (Blue), FL-RBL-HB-RD (Red), FL-RBL-HB-AM (Amber), and FL-RBL-HB-GR (Green)
ETL-RBL-HB-XX Colors: ETL-RBL-HB-WW (Warm White), ETL-RBL-HB-W (Cool White)
UL-RBL-HB-XX Colors: UL-RBL-HB-WW-2700K (Warm White), UL-RBL-HB-WW (Warm White), UL-RBL-HB-W (Cool White)


ACCESSORIES TO USE WITH THIS RIBBON:

Connectors: 12VDC WC2-10 / JC2-10, 24VDC WC2-8 / JC2-8
Controllers for FL-RBL-HB-RGB: RGB Controllers
Track that can be used with this ribbon: TRACK2 or TRACK3
