Flexible Ribbon Ultra High Brightness Led Strip (Non-Waterproof)

NEW UL 32.50 feet, 600 LEDs, 24VDC, 144W RGB roll available: Part# UL-RBL-UHB-RGB-10M

TECHNICAL PARAMETERS:

Led Light Source: 0.3W 5050 SMD LED
Standard: 300 LEDs per roll (16.25 feet), 600 LEDs per roll (32.50 feet for Ref# UL-RBL-UHB-RGB-10M)
Beam Angle: 120 degrees
Working Voltage: 12V DC (UL-RBL-UHB-XX), 24VDC (ETL-RBL-UHB-XX & UL-RBL-UHB-RGB-10M)
Working Current: 1.2A per meter (3.28 feet)
Power Consumption: 5 watts per foot (80watts per roll), 144watts per roll for Ref# UL-RBL-UHB-RGB-10M
Led Light Output Per Roll: 7200lm/roll
Package: 16.25 feet per roll (5 meters)
IP Rating:IP20
CRI:>90

Part Numbers:
ETL-RBL-UHB-XX Colors: ETL-RBL-UHB-WW (3000K, Warm White), ETL-RBL-UHB-NW (4000K, Neutral White) ETL-RBL-UHB-W (6000K, Cool White), ETL-RBL-UHB-RGB (Multiple Color Change)
UL-RBL-UHB-XX Colors: UL-RBL-UHB-WW-2700K (Warm White, 2700K), UL-RBL-UHB-WW (3000K, Warm White), UL-RBL-UHB-NW (4000K, Neutral White)UL-RBL-UHB-W (6000K, Cool White), UL-RBL-UHB-RGB (Multiple Color Change), FL-RBL-UHB-RGB-10M (Multiple Color Change 32.50ft Roll)



ACCESSORIES TO USE WITH THIS RIBBON:

Connectors: WC2-12 / JC2-12
Connectors RGB: WC4-12 / JC4-12
Track that can be used with this ribbon: TRACK0 or TRACK1 or TRACK18-N
